-Equipment adopts supercharger and fast nitrogen producing system.
-Compressed air is filtered twice
-Equipments also adopts water cooling and constant temperature device to guarantee the safety use of charging hose.
Vehicle applicable : motorcycles, cars, vans, mini-buses and trucks
Power supply : AC220V/380V/50Hz
Power : 2.0 Kw
Nitrogen purity : 95%
Compressed air pressure required : < 145Psi/10Bar/10Mpa
Air Compressor discharge rate : > 1.08M3/Min
No supercharger, Output Nitrogen pressure : 87 Psi/6 Bar/6 Mpa
Supercharged Nitrogen Output : 232 Psi/16 Bar/16 Mpa
Operation Temperature : +5? ~ +70?
Nitrogen producing speed : 160L/Min
Truck tyre : 15 tyres/hour [10.00/20 R 75 size]
Dimension : 1700(H) × 800(L) × 600(W)mm
Net weight : 265 kg
Gross weight : 288 kg
Packing size : 1920(H) × 960(L) × 770(W) mm
Storage Tank Packing size : 620×1750(mm)
Storage Tank Weight : 97 kg
