FEATURES
SPECIFICATION VIEW
| Outside Clamp | 11”- 24” |
| Inside Clamp | 13”- 26” |
| Max. wheel diameter | 1100 mm |
| Tyre width | 3" - 14" |
| Bead-breaker opening | 380 mm |
| Bead-breaker power | 15000 N |
| Working air pressure | 8 - 10 bar |
| Motor Power (pedal control two speed motor) | 0.85 kW - 1.1 kW |
| Chuck rotation speed | 7 rpm - 2V 6.5 - 13 rpm |
| Noise level running | < 70dB |
| Nett weight machine | 255 kg |
| Gross weight machine | 295 kg |
| Max dimension packaging | 1150 x 920 x 1000 mm |
| for 40” container | 46 pcs |
