- External clamping : 12" - 28"
- Internal clamping : 14" - 30"
- Max. wheel diameter : 1,200 mm / 47"
- Max.wheel width : 370 mm / 15"
- Bead breaker cylinder force at 10 bar : 2,500 kg
- Operating Pressure : 10 bar (140 psi)
- Max inflating pressure : 3.5 bar (50 psi)
- Power requirement : 415V/50HZ/3PH
FEATURES
Feature :
• Tilting vertical arm with pedal control
• Pneumatic system for locking the operating arm
• 28" turntable
• Bead breaker with double effect Pneumatic cylinder
• Oversize body
• Extractable pedal unit
• Double turntable speed for 3PH
SPECIFICATION VIEW
